Separable Transform: 2-D FFT

Back to Online Demo page    Original M file    Slideshow    DIP Home

% Note: only part of the code are shown here, look at the original M file to check out details

% ----------- Section 2: FFT --------------------------------------
% intuition on image transform
% example: natrual image:   lena and lowlibrary
% and artificial image:     stripes

% 1. Bright Dot in the center <-----> DC componet <-----> low pass characteristics of image:
% 2. Any idea what does the slant lines mean?
% (continue ...)

% Back to 1-D case
% Step function <---> Sinc


% look at the stripes again:

% Take a non-trivial example:

% Architects often talk about the balance between horizontal and vertical lines

% Now see how this is true in frequency domain
% Take part of this image (256x256), do 2-D FFT
